Realtime Decisions

Most operations in a system typically require decisions to be made to ensure that logical execution flow is followed and that business policies are adhered with.

Decisions are choices which determine a course of actions and steer the outcome of a process toward a goal. The faster compute and data access becomes, the faster decisions are being made. Decisions don’t always however result in achieving the desired result, at least not without further correction.

Motivation

Typically decision making occurs by following a series of steps, and therefore lends itself to automation. Generalization of these steps assists in reuse of the process for future decision making.

Glossary

Term	Description
Problem	The object state or condition upon which a decision must be made
Choice	The options which may be used to improve or maintain a state or condition
Decision	A single choice which may have several associated actions, which when implemented have the objective to improve or maintain a state or condition
Action	An operation performed as an outcome of a Decision, which modifies or maintains the current state or conditions of a system
Problem Job	The object which acts as the responsibility for resolving a Problem
Problem Queue	An ordered collection of Problems, sorted by typically by priority, severity and urgency

Modes

Type 1. Sequential Problem Solver

graph TD dp0(Start) dp1(Check State) dp2[Problem Queue] dp4[Scheduler] dp5[Resources] dp6[Runner] tp0[Problem Job] tp1(Analysis) tp2[Decision/s] tp3[Action/s] dp0 --> dp1 subgraph Coordinate dp1 ==Update==> dp2 dp6 --> dp1 dp6 -.Create and Dispose.-> dp5 dp4 --Schedule and Action--> dp6 dp5 -.-> dp1 end subgraph Job tp0 --> tp1 dp2-->tp0 tp1 -->tp2 dp5 -.Availability.-> tp1 dp4 -.Schedule.-> tp1 tp2 --> tp3 end tp3 --> dp4

Type 2. Parallel Problem Solver

graph TD dp0(Start) dp1(Check State) dp2[Problem Queue] dp3[Job Manager] dp4[Scheduler] dp5[Resources] dp6[Runner] tp0[Problem Job] tp1(Analysis) tp2[Decision/s] tp3[Action/s] dp0 --> dp1 subgraph Coordinate dp1 ==> dp2 dp2 ==> dp3 dp4 --Schedule and Action--> dp6 dp6 -.Create and Dispose.-> dp5 dp6 --> dp1 dp3 ==> dp1 dp5 -.-> dp1 end subgraph Job tp0 --> tp1 tp1 --> tp2 tp2 --> tp3 end dp3 --> tp0 tp3 --> dp4 dp4 -.Schedule.-> tp1 dp5 -.Availability.-> tp1

Generalization

graph LR Start --> State State --> Review Review --No Problem/s--> Stop Review --New Problem/s--> Problem Problem --> Analysis Analysis --> Goal Analysis --> Policies Analysis --> Choices Analysis --> Dependencies Analysis --> Sequence Goal --> Decision Policies --> Decision/s Choices --> Decision/s Dependencies --> Decision/s Sequence --> Decision/s Decision/s --> Action/s Action/s --> State Goal --> Review

Important points to note:

State

State can rapidly change, and this rate of change may further influence the rate at which
- Analysis must be resolved
- Decisions must be made
- Actions must be taken
- Outcomes must be measured
State may be very complex
- Historical Problems, Decisions, Actions and Outcomes already implemented
- Current Problems, Choices, Decisions, Actions yet to be acted upon or planned
- External influences may prevent state from being fully known
- Actions yet to be made may alter the state, and therefore Decisions already made may be impacted

Problems

Problems are always from a particular perspective, therefore
- regularly reviewing how problems are detected will have a flow on benefit to ensure issues detected regularly
- learning from failure to detect will improve problem detection in the future
- perspectives are influenced by policy
While solving one Problem, a new Problem may be observed
Problems may be contributing positively to the current state as well as negatively
Sometimes the Decisions may make the problem worse

Goals

Goals are normally designed from a single perspective
Multiple parties may benefit from a Goal being achieved and not all aspects of this may be desirable
Goals may change over time
Goals may be relevant within a specific window of conditions, or expire
A valid goal may be to have nothing happen

Choice

Choices made in the past may not be possible in future scenarios
Choices may be invalidated by the time they are implemented
Choices typically require resources to Action, therefore
- resource contention must be managed
- resource availability must be ensured before an Action commences, otherwise the Outcome will not be achieved
Choices may create products and by-products, and therefore
- products need to be correctly managed
- by-products need to be managed or disposed, to prevent further downstream problems being created
Choices typically

Decisions

The objective of making Decisions is to improve (or at least maintain) a system
Decisions are never made to degrade the long-term outcome of a system, and therefore
- the concept of time is relevant to the measure of success
- to measure the success of an Action, a maximum time for an action to influence a system should be planned and capped
Decisions are made with respect to the available information, including state, historical activity and future goals
Decisions may sometimes need to be made before all Choices are known

Actions

Actions are not necessarily repeatable
Actions typically cannot be undone
Actions may not always achieve the same outcome when repeated

Outcome

Outcomes are not always permanent
Outcomes may not be deemed as positive at some later point in time

Analysis

graph TD subgraph Problem Domain p[Problem] pd[Problem Domain] g0[Current State] g1[Goal State] m[Success Measure] l[Policies] m0[Problem Gap] pd --- p pd --- l p --> g0 p --> g1 m -.-> m0 pd --- m end subgraph Analysis a --> al g0 --> m1 g0 --> m0 g1 --> m0 m0 --> m2 ac1 --> m1 m -.-> m1 subgraph Choice Domain al[Action/s] c[Choices] d[Decision/s] al ==> c c ==> d l -.Constrains.-> d end subgraph Action Domain a[Action] ad[Action Definition] ac3[Sequence] ac4[Resources] ac5[Duration] ac0[Entry State] ac1[Exit State] ac2[Fail Conditions] ad --> ac3 ad --> ac4 ad --> ac5 ad --> ac0 ad --> ac1 ad --> ac2 m1[Action Gap] m2[Correction] m1 --> m2 ac3 --> a ac4 --> a ac5 --> a ac0 --> a ac1 --> a ac2 --> a m2 -- Predicted Improvement --> a end end

Analysis - A Mathematical Approach

Let,

$S(t)$ be the state of the system at time t, where $S(0)$ is now.
$A_{entry}(t)$ be the Action ‘entry state’ of the system at time t
$A_{exit}(t)$ be the Action ‘exit state’ of the system at time t
$n$ be the number of possible Actions
$p$ be the number of possible Actions for a specific choice
$q$ be the number of possible Choices

Effect of change

\[E_{change}(t) = A_{exit}(t) - S(t)\]

However, if no change has occurred since the action commences, this can be simplified

\[E_{change}(t) = A_{exit}(t) - A_{entry}(t)\]

Therefore where no Action occurs

\[E_{change}(t) = 0\]

Selecting the optimum action

The measure of success of a single Action can be determined as a function of the current state and the exit state of the Action.

\[m_{action}(t) = \lvert A_{exit}(t) - S(t) \rvert \\ = \lvert E_{change} \rvert\] \[M_{action}(t) = \begin{cases} 0, \text{if t < 0} \\ m_{action}(t_{0}) - c, \text{if t = 0} \\ \alpha (m_{action}(t_{0+x}) - c), \text{if t > 0} \ \end{cases}\]

Where:

$m_{action}(t)$ is an assessment made at some point in time, $t$
$\alpha$ is a decay factor degrading the benefit of the change over time
$c$ is an offset weight to encourage doing some action

Performing no Action reveals the current state is maintained, if c = 0:

$M_{action}(0) = \lvert 0 - S(0) \rvert + 0 = S(0) $

Performing an Action, and assessing at an arbitrary point in the future,

$M_{action}(t_{1}) = \alpha \lvert A_{exit}(t_{1}) - S(t_{0}) \rvert + c$

Our assessment of the outcome can be shown to be heavily influenced by the decay $ \alpha$.

A system which degrades quickly, (high $\alpha$) requires significant effort to maintain.
A system which degrades slowly, requires minimal effort to maintain.

The selection of the optimum Action to take, can be found by finding the local maxima, for all possible Actions.

\[M_{MAX action}(t) = \max(\{M_{action_{0}}(t), ... , M_{action_{n-1}}(t)\})\]

Selecting the optimum decision

Typically a Choice will have more than one Action, associated with it. The Runner will execute all Actions, not simply the best Action, as the system must be left in a stable and consistent state.

Let:

$m_{choice}(t, a)$ be the measure of success of an Action, for a given choice, where the choice has several possible Actions
$a$ be the selected Action

The measure of success of a single Choice can be determined as a sum of the related Actions of that Choice. In short, each action effects the success, and the choice success can be measured as

\[M_{choice}(t) = \sum_{a=0}^{n-1} m_{choice}(t, a) \\ = \sum_{a=0}^{n-1} m_{action_{a}}(t)\]

The best Choice to make is therefore, the maximum for all possible Choices, $q$.

\[M_{MAX choice}(t) = \max(\{ M_{choice(0)}{1}(t), ... , M_{choice(q-1)}(t)\})\]

However, it should be noted that this is only true, if the measurement of success uses a consistent time $t$ and $\alpha$ and $c$ for all assessments.

In reality, some Actions may degrade faster than others, due to their impact on the system and the systems resistance to that change.
